LG 65EF9500 - RF Input; HDMI Input (PC); HDMI1.4;2.0 (3 D Supported Mode Manually); 3 D Mode(3 D Supported Mode Manually)

- 9 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.4. HDMI Input (PC)
No Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remarks
1 640*350 31.46 70.09 25.17 EGA
2 720*400 31.46 70.08 28.32 DOS
3 640*480 31.46 59.94 25.17 VESA(VGA)
4 800*600 37.87 60.31 40.00 VESA(SVGA)
5 1024*768 48.36 60.00 65.00 VESA(XGA) FHD only
6 1152*864 54.34 60.05 80.00 VESA
7 1280*1024 63.98 60.02 109.00 VESA(SXGA) FHD only
8 1360*768 47.71 60.01 85.00 VESA(WXGA) UHD only
9 1920*1080 67.50 60.00 158.40 WUXGA(CEA 861D) UHD only
10 3840*2160 67.50 30.00 297.00 UDTV 2160P UHD only
11 3840*2160 56.25 25.00 297.00 UDTV 2160P UHD only
12 3840*2160 54.00 24.00 297.00 UDTV 2160P UHD only
13 4096*2160 53.95 23.97 296.703 UDTV 2160P UHD only
14 4096*2160 54.00 24.00 297.00 UDTV 2160P UHD only
6. 3D Mode(3D supported mode manually)
6.1. RF Input
No Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remarks
1 1280*720 37.50 50 74.25 HDTV 720P 2D to 3D, Side by Side, Top & Bottom
2 1920*1080 28.13 50 74.25 HDTV 1080I 2D to 3D, Side by Side, Top & Bottom
6.2. HDMI Input
6.3. HDMI1.4/2.0 (3D supported mode manually)
No Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remarks
1 720*480 31.469/31.5/62.938/63 59.94/59.94/60 27.00 /27.03 SDTV 480P 2D to 3D, Side by Side(Half),
Top & Bottom, Checker
Board, Row Interleaving,
Column Interleaving
2 1280*720 45.00 60.00 74.25 HDTV 720P
37.50 50.00 74.25 HDTV 720P
3 1920*1080 33.75 60.00 74.25 HDTV 1080I 2D to 3D, Side by Side(Half),
Top & Bottom
28.12 50.00 74.25 HDTV 1080I
4 1920*1080 27.00 24.00 74.25 HDTV 1080P 2D to 3D, Side by Side(Half),
Top & Bottom, Checker
Board, Row Interleaving,
Column Interleaving
28.12 25.00 74.25 HDTV 1080P
33.75 30.00 74.25 HDTV 1080P
67.50 60.00 148.50 HDTV 1080P 2D to 3D, Side by Side(Half),
Top & Bottom,
Checker Board,Row Inter-
leaving, Column Interleaving
56.25 50.00 148.50 HDTV 1080P
5 3840*2160
4096*2160
53.95 23.98 297.00 HDTV 2160P 2D to 3D,
Top & Bottom(half), Side by
Side(half),
54.00 24.00 296.70
56.25 25.00 297.00
61.43 29.97 297.00
67.50 30.00 296.70
135.00 60.00 594.00
