33
ENGLISH
HDMI 1 / HDMI 2 / DisplayP
ort (PC) Suppor
t Mode
Resolution
Horizontal fr
equency (kHz)
V
ertical frequency (Hz)
800 x 600
37.879
60.317
1024 x 768
48.363
60
1280 x 720
44.772
59.855
1280 x 1024
63.981
60.02
1680 x 1050
65.29
59.954
1920 x 1080
67.5
60
3840 x 2160
67.5
30
3840 x 2160
135
60
HDMI 1 / HDMI 2 / DisplayP
ort (DTV) Support mode
Resolution
Horizontal frequency (kHz)
V
ertical frequency (Hz)
480/60p
31.5
60
576/50p
31.25
50
720/50p
37.5
50
720/60p
45
60
1080/50i
28.1
50
1080/60i
33.75
60
1080/50p
56.25
50
1080/60p
67.432
59.94
1080/60p
67.5
60
2160/30p
67.5
30
2160/50p
112.5
50
2160/60p
135
60
32
34
Table of Contents
Table of Contents
2
Safety Precaution
3
Precautions for the AC Adapter and Power
4
Precautions for Moving the Product
6
Precautions for Installing the Product
7
Precautions for Cleaning the Product
9
Precautions for Using the Product
10
Precautions for Using the Remote Control
12
Precautions for Experiencing Image Retention
13
Product Disposal
13
Licenses
14
Assembly and Preparation
15
Parts and Buttons
16
Portrait Layout
17
Attaching and Removing the LG Logo Bracket
18
Installing on a Wall
20
Safety and Precaution Guide for Installation
22
Remote Control
23
Making Connections
25
Connecting to a PC
25
External Device Connection
25
Connecting Multiple Monitors
27
Using the Input List
27
Troubleshooting
28
Product Specifications
31
User Manual Lg Digital Signage
37
Safety Precautions
39
Precautions for the AC Adapter and Power
40
Precautions for Moving the Product
42
Precautions for Installing the Product
43
Precautions for Cleaning the Product
45
Precautions for Using the Product
46
Precautions for Using the Remote Control
48
Precautions for Experiencing Image Retention
49
Product Disposal
49
Using the Remote Control
50
Connecting to a PC
53
External Device Connection
53
Making Connections
53
Connecting Multiple Monitors
55
Dashboard [Content Manager] [Gallery Mode]
56
Global Buttons
56
Home
56
Settings
56
Ez Setting
57
[On/Off Scheduler]
57
[SI Server Setting]
57
[Video Wall]
57
[Fail Over]
58
[Server Setting]
58
[Status Mailing]
58
[Play Via URL]
60
[Setting Data Cloning]
60
[Sync Mode]
60
[Multi Screen]
62
[Leveler Tool]
64
[Office Meeting Mode]
64
General
65
[Set ID]
65
[System Information]
65
[Time & Date]
65
[Safety Mode]
71
[Audio Guidance]
73
[Advanced Setting]
74
Display
78
[Picture Mode]
78
[Aspect Ratio]
81
[Advanced Setting]
82
Sound
86
[Sound Mode]
86
[Sound Out]
87
[Audio Out]
88
[AV Sync Adjustment]
88
[Digital Audio Input]
88
Admin
89
[Lock Mode]
89
[Change Password]
90
[Enterprise Settings]
90
[Factory Reset]
90
Content Manager
91
Web Login
91
Group Manager 2.0
98
Gallery Mode
101
Screenshare
102
LG Presenter
103
Connect
104
Handover
105
Screen Share
105
Control Manager
106
Management Tools
106
Picture ID
107
Connecting to a PC
108
Prioritized Tasks on the Touch Screen
108
To Control an External Pc Using Touch Screen
108
How to Run
109
Smart Calibration
109
[Manual Calibration]
110
Ir Code
111
Connecting Cables
113
Controlling Multiple Products
113
Communication Parameter
114
Command Reference List
115
Command 1
116
Table of Contents
119
Transmission/Reception Protocol
120
Aspect Ratio] K C
121
Select Input X B
121
Picture Mode] D X
122
Color Temperature] X U
123
Mute On] K E
123
Sound Mode] D y
123
Volume Control K F
123
Current Time] 1 (Year/Month/Day)
124
Current Time] 2 (Hour/Minute/ Second) F X
124
Current Temperature D N
125
Default Settings F K
125
Time Elapsed D L
125
Average Picture Level Auto Control]
142
Frame Control] S N, B7
142
Dynamic Tone Mapping] S N, C5
143
HDR Picture Mode] S N, C4
143
LED Local Dimming] S N, C6
143
Read Brightness Value M U
143
Screen Fault Detection]
143
Stereo Mode] S N, C2
143
Brightness Range Adjustment] S N, Ab
144
Change Password] S N, A7
144
Color Calibration] S N, D6
144
Quiet Mode] S N, C7
144
USB2 to Hdbaset] S N, C3
144
Automatic Adjustment J U
145
Horizontal Location F Q
145
Horizontal Size F S
145
Intelligent Auto
145
Vertical Location F R
145
Troubleshooting
146
