64 Free Joint Multi Air Conditioner
Exploded View & Replacement Parts List
PART No.
AMNH186LTL0 AMNC186LTL0 AMNH246LTL0 AMNH246LTA0 AMNC246LTL0
131410 CHASSIS ASSEMBLY 3141A10002A 3141A10002A 3141A10002A 3141A10002A 3141A10002A R
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10116A 3531A10116A 3531A10116A 3531A10116A 3531A10116A R
135314 GRILLE ASSEMBLY,INLET SUB 3531A20107W 3531A20107V 3531A20107W - 3531A20107V R
135316 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A20207E 3531A20207F 3531A20207E 3531A24010F 3531A20207F R
135516 COVER ASSEMBLY,MOTOR 3551A20099C 3551A20099C 3551A20099C 3551A20099C 3551A20099C R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A 4681A20055A R
152302 FILTER(MECH),A/C 5230A20001A 5230A20001A 5230A20001A 5230A20001A 5230A20001A R
159830 AIR CLEANER ASSEMBLY 5983A10006T 5983A10006T 5983A10006T - 5983A10006T R
159901-1 VANE,HORIZONTAL 5990A20008A 5990A20008A 5990A20008A 4995A11004D 5990A20008A R
159901-2 VANE,HORIZONTAL 5990A20009A 5990A20009A 5990A20009A 5990A20009A 5990A20009A R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20361E 4995A20361K 4995A20361F 4995A20361F 4995A20361L R
263230-1 THERMISTOR ASSEMBLY 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T 6323AQ3226T R
263230-2 THERMISTOR ASSEMBLY 6323A20004A 6323A20004A 6323A20004A 6323A20004A 6323A20004A R
266090 H.V ASSEMBLY 6609A10003L 6609A10003L 6609A10003L - 6609A10003L R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20067J 6711A20067H 6711A20067J 6711A20083F 6711A20067H R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20194B 6871A20194B 6871A20194B 6871A20194B 6871A20194B R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20267B 6871A20267B 6871A20267B 6871A20267B 6871A20267B R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20440E 6871A20440L 6871A20440F 6871A20440F 6871A20440M R
342800 BEARING 4280A20004A 4280A20004A 4280A20004A 4280A20004A 4280A20004A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20003D 4681A20003D 4681A20067A 4681A20067A 4681A20067A R
352111 TUBE ASSEMBLY,CONNECTOR 5211A20514B 5211A20514B 5211A20514B 5211A20514B 5211A20514B R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A30058H 5211A30058H 5211A30097J 5211A30097J 5211A30097J R
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A30057D 5211A30057D 5211A30098G 5211A30098G 5211A30098G R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F 5251AR2575F R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20008A 5901A20008B 5901A20008A 5901A20008A 5901A20008B R
733010 PLATE ASSEMBLY,INSTALL 3301A10002A 3301A10002A 3301A10002A 3301A10002A 3301A10002A R
35211B TUBE ASSEMBLY,TUBING 5211A30439E 5211A30439E 5211A30439J 5211A30439J 5211A30439J R
W0CZZ CAPACITOR,DRAWING 3H01487G 3H01487G 3H01487G 3H01487G 3H01487G R
DESCRIPTION
SVC
CODE
LOCATION
No.
