- 5 -
Copyright ©2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4. Wiring Diagrams
CN-L1
CN-N1
CN-COM CN-EARTH
CN-MOTOR1
CN-ACDC2
CN-TH2
CN-TH3
CN-TH1 CN-UD1 CN-LR1
CN-D1 CN-LR2 CN-CC
CN-ACDC2
CN-REMO
AC ASM
DC ASM
