LG AMNW09GEBA0 Svc Manual

- 2 -
Copyright ©2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. Specification
Indoor
Note:
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 27°C(80.6°F) DB/19°C(66.2°F) WB
- Outdoor Temperature 35°C(95°F) DB/24°C(75.2°F) WB
Heating: - Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB
- Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) WB
Piping Length - Interconnecting Piping Length 7.5m
- Level Difference of Zero
2. Wiring cable size must comply with the applicable local and national code.
3. The specification may be subject to change without prior notice for purpose of improvement.
Conversion Formula
kW = Btu/h x 0.0002931
cfm = CMM x 35.3
Power supply Ø/V/Hz
Current A
Fan Motor type
Fan type
Dimensions (W x H x D) mm(inch)
Piping Liquid mm(inch)
connections Gas mm(inch)
Refrigerant control
Power&transmission cable No. x mm
2
Model
AMNW09GEBA0
[MS09SQ NB0]
AMNW12GEBA0
[MS12SQ NB0]
AMNW15GEBA0
[MS15SQ NB0]
1/ 220~240/ 50 1/ 220~240/ 50 1/ 220~240/ 50
0.2 0.2 0.2
BLDC BLDC BLDC
Cross Flow Fan Cross Flow Fan Cross Flow Fan
895 x 289 x 215 (35-1/4 x 11-3/8 x 8-15/32) 895 x 289 x 215 (35-1/4 x 11-3/8 x 8-15/32) 895 x 289 x 215 (35-1/4 x 11-3/8 x 8-15/32)
6.35 (1/4) 6.35 (1/4) 6.35 (1/4)
9.52 (3/8) 9.52 (3/8) 9.52 (3/8)
EEV(in Outdoor unit or BD) EEV(in Outdoor unit or BD) EEV(in Outdoor unit or BD)
4
x 0.75 4 x 0.75 4 x 0.75
