1. Specification
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m(24.6ft)
• Level Difference of Zero
Heating • Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
• Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
• Interconnecting Piping Length 7.5m(24.6ft)
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without prior notification
4. To be added for more available Models
5. EEV : Electronic Expansion Valve
Conversion Formula
kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
l/s = CMM x 1000/60
Type Floor Standing
Model Unit ARNU07GCEA4 ARNU09GCEA4 ARNU12GCEA4
Cooling Capacity
kW 2.2 2.8 3.6
kcal/h 1,900 2,400 3,100
Btu/h 7,500 9,600 12,300
Heating Capacity
kW 2.5 3.2 4
kcal/h 2,200 2,800 3,400
Btu/h 8,500 10,900 13,600
Casing
Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions
(WxHxD)
Body
mm 1,067 x 635 x 203 1,067 x 635 x 203 1,067 x 635 x 203
inch 42 x 25 x 8 42 x 25 x 8 42 x 25 x 8
Coil
Rows x Columns x FPI 2 x 12 x 19 2 x 12 x 19 2 x 12 x 19
Face Area m
3
0.16 0.16 0.16
Fan Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output x Number W 19 x 1, 5 x 1 19 x 1, 5 x 1 19 x 1, 5 x 1
Running Current A 0.76 0.76 0.76
Air Flow Rate(H / M / L)
CMM 8.5 / 7.5 / 6.5 9.5 / 8.5 / 7.5 10.5 / 9.5 / 8.5
cfm
300 / 265 / 229 335 / 300 / 265 371 / 335 / 300
Drive Direct Direct Direct
Motor type BLDC BLDC BLDC
Temperature Control
Microprocessor,
Thermostat for cooling
and heating
Microprocessor,
Thermostat for cooling
and heating
Microprocessor,
Thermostat for cooling
and heating
Sound Absorbing Thermal Insulation Material Foamed polystrene Foamed polystrene Foamed polystrene
Air Filter Resin Net(washable) Resin Net(washable) Resin Net(washable)
Safety Device Fuse Fuse Fuse
Pipe
Connections
Liquid Side
mm(inch) Ø6.35(1/4) Ø6.35(1/4) Ø6.35(1/4)
Gas Side mm(inch) Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2)
Drain Pipe(Internal Dia.) mm(inch) 12(15/32) 12(15/32) 12(15/32)
Net Weight
kg(lbs) 27(59.5) 27(59.5) 27(59.5)
Noise Level(Sound Press, 1m, H / M / L) dB(A)+1 35 / 33 / 31 36 / 34 / 32 37 / 35 / 33
Power Supply Ø, V, Hz
1, 220-240, 50 1, 220-240, 50 1, 220-240, 50
1, 220, 60
1, 220, 60 1, 220, 60
Refrigerant Control EEV EEV EEV
Power cable
mm
2
CV1.5 x 3C CV1.5 x 3C CV1.5 x 3C
Transmission Cable(AWG#-C) mm
2
CVV-SB 1.0~1.5 x 2C CVV-SB 1.0~1.5 x 2C CVV-SB 1.0~1.5 x 2C
