LG ARNU093BHA2 - Dimensional Drawings and Measurements; Unit External Dimensions; Center of Gravity Location

ARNU093BHA2
MultiV™Ducted(HighStatic)
Btu/hIndoorUnit
JobName/Location:
Tag#:
Date:
PONo.:
ARNU093BHA2
Center of Gravity
Note‐Alldimensionshavea
toleranceof±0.25in.
=Centerofgravity
9,600
Page2of2VRF‐SB‐DF‐002‐US012D18
