100 | HIGH STATIC
MULTI V Ducted Indoor Unit Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Heating Capacity Tables
DUCTED HIGH STATIC
ARNU093BHA4
Table 63: ARNU093BHA4 Heating Capacity Table.
Model No./
Capacity Index
Outdoor
Air Temp.
Indoor Air Temperature (°F DB)
59 61 64 67 70 73 76 80
°F DB °F WB TC TC TC TC TC TC TC TC
ARNU093BHA4/
9.5
-21.6 -22.0 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
-17.1 -17.5 6.2 6.2 6.2 6.2 6.1 6.1 6.1 6.1
-12.6 -13 6.9 6.9 6.9 6.9 6.8 6.8 6.8 6.8
-7 -7.6 7.1 7.1 7.1 7.1 7.0 7.0 7.0 7.0
-4 -4.4 7.3 7.3 7.3 7.3 7.2 7.2 7.2 7.2
0 -0.4 7.5 7.5 7.5 7.5 7.5 7.4 7.4 7.4
5 4.5 8.5 8.4 8.3 8.3 8.3 8.3 8.3 8.3
10 9 8.8 8.8 8.8 8.7 8.7 8.7 8.7 8.7
15 14 9.4 9.4 9.4 9.4 9.4 9.4 9.3 9.2
20 19 9.9 9.9 9.9 9.9 9.7 9.7 9.5 9.4
25 23 10.4 10.4 10.4 10.4 10.4 10.1 10.0 9.5
30 28 10.6 10.6 10.6 10.6 10.6 10.4 10.0 9.5
35 32 10.9 10.9 10.9 10.9 10.8 10.6 10.0 9.5
40 36 11.3 11.3 11.3 11.3 10.9 10.6 10.0 9.5
45 41 11.8 11.8 11.8 11.5 10.9 10.6 10.0 9.5
47 43 12.2 12.1 12.0 11.5 10.9 10.6 10.0 9.5
50 46 13.1 12.5 12.0 11.5 10.9 10.6 10.0 9.5
55 51 13.4 12.6 12.0 11.5 10.9 10.6 10.0 9.5
60 56 13.4 12.6 12.0 11.5 10.9 10.6 10.0 9.5
TC: Total Capacity (MBh).
The System Combination Ratio must be between 50–130%.
Rated capacity is certified under AHRI Standard 1230. Ratings are subject to change
without notice.
Current certified ratings are available at www.ahridirectory.org.
For outdoor unit performance data, see the respective outdoor unit performance data
manuals on https://lghvac.com/commercial.
Low ambient performance with LGRED° heat technology is included in Multi V 5 Air Source Units produced after February 2019.
