38 | HIGH STATIC
MULTI V Ducted Indoor Unit Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
External Static Pressure Ranges
DUCTED HIGH STATIC
BH Units
Table 24: BH Unit External Static Pressure Ranges.
Model Capacity (MBh) Mode Setting Value Standard ESP (in. wg) CFM Min. ESP (in. wg) Max. ESP (in. wg)
ARNU073BHA4 7.5
High
(Factory Set)
Hl 120
0.31
230
0.23 0.47Mid 117 205
Low 115 191
Standard
Hl 110
0.23
258
0.15 0.31Mid 107 222
Low 105 198
ARNU093BHA4 9.6
High
(Factory Set)
Hl 125
0.31
286
0.23 0.47Mid 120 230
Low 117 205
Standard
Hl 110
0.23
258
0.15 0.31
Mid 107 222
Low 105 198
ARNU123BHA4 12.3
High
(Factory Set)
Hl 130
0.31
339
0.23 0.47Mid 125 286
Low 120 230
Standard
Hl 115
0.23
307
0.15 0.31Mid 110 258
Low 105 198
ARNU153BHA4 15.4
High
(Factory Set)
Hl 135
0.31
399
0.23 0.47Mid 130 339
Low 120 230
Standard
Hl 123
0.23
388
0.15 0.31Mid 120 357
Low 115 307
ARNU183BHA4 19.1
High
(Factory Set)
HI 140
0.31
459
0.23 0.47Mid 135 399
Low 130 339
Standard
HI 130
0.23
466
0.15 0.31Mid 125 413
Low 110 258
ARNU243BHA4 24.2
High
(Factory Set)
HI 150
0.31
565
0.23 0.47Mid 145 509
Low 140 459
Standard
HI 145
0.23
618
0.15 0.31Mid 135 519
Low 128 445
The table above shows the available E.S.P. range.
