48 | HIGH STATIC
MULTI V Ducted Indoor Unit Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Model Rating
Fan
speed
E.S.P RPM CFM
Sound pressure level, Lp (dB one reference picopascals)
63Hz 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz
ARNU423M2A4
RETURN OPENING
H
0.20
1170 1262 36 46 44 46 46 40 33 27
M 1080 1087 33 44 41 43 43 37 30 24
L 1000 917 37 39 39 42 41 35 28 21
CASING RADIATED
H 1170 1262 33 46 44 42 43 38 30 23
M 1080 1087 29 43 41 38 40 34 27 19
L 1000 917 34 36 38 37 37 33 24 15
DUCTED DISCHARGE
H 1170 1262 48 43 47 49 50 45 39 36
M 1080 1087 45 41 45 46 47 42 36 33
L 1000 917 43 41 41 44 44 39 33 28
ARNU363M2A4
RETURN OPENING
H
0.20
1050 1021 33 43 41 43 43 36 30 24
M 970 844 36 38 39 42 41 34 27 21
L 910 695 35 40 38 41 39 32 25 17
CASING RADIATED
H 1050 1021 29 42 40 38 39 34 26 18
M 970 844 33 36 38 37 37 32 24 15
L 910 695 31 36 38 34 33 28 19 12
DUCTED DISCHARGE
H 1050 1021 45 40 44 46 46 42 35 32
M 970 844 43 40 41 44 44 39 32 28
L 910 695 43 38 40 42 42 37 29 23
ARNU283M2A4
RETURN OPENING
H
0.20
990 892 37 39 40 43 42 35 28 22
M 940 770 36 41 39 42 40 33 26 18
L 890 645 35 40 38 41 39 32 25 17
CASING RADIATED
H 990 892 35 37 39 38 38 33 25 16
M 940 770 33 37 39 35 35 29 20 14
L 890 645 31 36 38 34 33 28 19 12
DUCTED DISCHARGE
H 990 892 44 41 42 45 45 40 33 29
M 940 770 45 39 42 43 43 38 31 24
L 890 645 43 38 40 42 42 37 29 23
ARNU243M2A4
RETURN OPENING
H
0.20
840 640 34 39 37 40 38 32 25 17
M 820 520 34 39 37 40 38 31 24 16
L 800 435 34 39 37 40 38 31 24 16
CASING RADIATED
H 840 640 30 35 37 33 32 27 18 11
M 820 520 30 34 36 33 32 26 17 11
L 800 435 29 34 36 32 32 26 17 10
DUCTED DISCHARGE
H 840 640 42 37 39 41 41 36 28 22
M 820 520 42 36 39 41 40 35 28 21
L 800 435 41 36 38 40 40 35 27 21
DUCTED HIGH STATIC
Acoustic Data
Sound Pressure Data for M2 Units
