HIGH STATIC | 57
Ducted High Static
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Model Rating
Fan
speed
E.S.P RPM CFM
Sound pressure level, Lp (dB one reference picopascals)
63Hz 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz
ARNU543M3A4
RETURN OPENING
H
0.79
1320 1477 41 45 43 45 47 38 33 26
M 1300 1398 41 45 43 45 47 38 33 26
L 1280 1306 41 45 43 45 47 38 33 25
CASING RADIATED
H 1320 1477 40 43 41 42 41 38 32 24
M 1300 1398 39 43 40 41 41 37 32 23
L 1280 1306 39 42 40 41 40 37 31 23
DUCTED DISCHARGE
H 1320 1477 58 52 46 49 50 47 41 33
M 1300 1398 57 52 46 49 50 47 41 33
L 1280 1306 57 52 45 49 50 47 41 33
ARNU483M3A4
RETURN OPENING
H
0.79
1280 1306 41 45 43 45 47 38 33 26
M 1260 1214 41 45 43 45 47 38 33 25
L 1200 868 40 44 42 44 46 37 32 25
CASING RADIATED
H 1280 1306 39 43 40 41 41 37 32 23
M 1260 1214 39 42 40 41 40 37 31 23
L 1200 868 38 41 39 40 39 36 30 22
DUCTED DISCHARGE
H 1280 1306 58 52 46 49 50 47 41 33
M 1260 1214 57 52 46 49 50 47 41 33
L 1200 868 57 51 45 48 49 46 40 32
ARNU423M3A4
RETURN OPENING
H
0.79
1260 1214 41 45 43 45 47 38 33 26
M 1220 988 40 44 43 45 47 37 33 25
L 1200 868 40 44 42 45 46 37 32 25
CASING RADIATED
H 1260 1214 39 43 40 41 40 37 32 23
M 1220 988 38 42 39 40 40 36 31 23
L 1200 868 38 42 39 40 39 36 31 22
DUCTED DISCHARGE
H 1260 1214 58 52 46 49 50 47 41 33
M 1220 988 57 52 45 49 50 47 41 33
L 1200 868 57 51 45 48 49 47 41 33
ARNU363M3A4
RETURN OPENING
H
0.79
1260 1214 41 45 44 46 47 38 34 26
M 1220 988 41 45 43 45 47 38 33 25
L 1200 868 40 45 43 45 47 37 33 25
CASING RADIATED
H 1260 1214 39 43 40 41 41 37 32 24
M 1220 988 39 42 40 41 40 37 31 23
L 1200 868 38 42 39 40 40 36 31 23
DUCTED DISCHARGE
H 1260 1214 58 52 46 50 51 48 42 34
M 1220 988 57 52 46 49 50 47 41 33
L 1200 868 57 52 45 49 50 47 41 33
ARNU283M3A4
RETURN OPENING
H
0.79
1240 1108 41 46 44 46 48 38 34 26
M 1200 868 41 45 43 45 47 38 33 26
L 1180 779 41 45 43 45 47 38 33 25
CASING RADIATED
H 1240 1108 40 43 41 42 41 38 32 24
M 1200 868 39 42 40 41 40 37 31 23
L 1180 779 39 42 40 41 40 37 31 23
DUCTED DISCHARGE
H 1240 1108 58 53 46 50 51 48 42 34
M 1200 868 58 52 46 49 50 48 41 34
L 1180 779 57 52 46 49 50 47 41 33
DUCTED HIGH STATIC
Acoustic Data
Sound Pressure Data for M3 Units
