11
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Table 2: Single Zone Art Cool Mirror Wall Mount Electrical Data.
Electrical Data
Indoor Unit Outdoor Unit Hertz Voltage
Voltage
Range
(Min. to
Max.)
MCA MOP
Com-
pressor
Quantity
Compressor
Motor RLA
Outdoor Fan
Motor
Indoor Fan
Motor
Cooling
Heat-
ing
W FLA W FLA
LAN090HSV5 LSU090HSV5
60 208 - 230 187 - 253
10.0 15.0 1 7.0 7.0 43 0.4 30 0.4
LAN120HSV5 LSU120HSV5
10.0 15.0 1 7.0 7.0 43 0.4 30 0.4
LAN180HSV5 LSU180HSV5
13.0 20.0 1 9.6 9.6 124 0.25 70 0.4
LAN240HSV3 LAU240HSV3 19.0 25.0 1 14.6 14.6 124 0.25 30 0.4
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as
follows: (Largest motor FLA x 2.25) + (Sum of other motor
FLA) rounded down to the nearest standard fuse size.
RLA = Rated Load Amps.
FLA = Full Load Amps.
W: Fan Motor Rated Output (W).
Electrical Data
