3. Installation Space
7
Multi V S Outdoor Unit
Installation of Outdoor Units
■ In case of obstacles on the suction and the discharge side
• Obstacle height of discharge side is higher than the unit
1. Stand alone installation
2. Collective installation
Chassis code U4 / U3 Chassis U7 Chassis
a 500 or more 700 or more
Note
• Depending on the sales region or product type, external appearance and applicability of each “Chassis” might be varied.
L
H
a
≤ 500
100 or
more
L
H
1,000 or
more
≤
500
500
500 or
less
250 or
more
1,000 or
more
L > H L > H
[Unit:mm]
L
H
1 000 or
more
300 or
more
or
more
100 or
1,000 or
more
L
H
300 or
more
1,250 or
more
500 or
less
L > H
[Unit:mm]
L > H
more
100 or
