Copyright ©2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
- 25 -
Wiring Diagrams
SW01D
SW01C
SW04C
SW03C
SW02C
MAIN EEV
SC EEV
HOT GAS
AC_INPUT
4 WAY
P_SEN_L
P_SEN_H
CN8
CN7
HIGH PRESSURE SW
AIR
SUCTION/HEX/
DISCHARGE
SC_OUT/LIQUID
CN_INV
n Main PCB
n PI485 PCB n Indoor Communication PCB
