60 Room Air Conditioner

Replacement Parts List

Parts List (Indoor)

LOCATION

DESCRIPTION

PART No.

REMARKS

No.

131410 CHASSIS ASSEMBLY 3141A20006A 3141A20006A 3141A20005A R

135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10232T 3531A10232T 3531A10234P R

135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A20225B 3531A20225B 3531A10174Z R

135314 GRILLE ASSEMBLY,INLET SUB 3531A20226B 3531A20226B 3531A10273A R

135516 COVER ASSEMBLY,MOTOR 3551A20050H 3551A20050H 3551A20050A R

146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A R

152302 FILTER(MECH),A/C 5230A10005C 5230A10005C 5230A20014B R

152313 FILTER ASSEMBLY,DEODORIZER - - - R

159830 AIR CLEANER ASSEMBLY - - - R

159901 VANE,HORIZONTAL 5990A10005A 5990A10005A 5990A20007A R

249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20257R 4995A20257B 4995A20258B R

263230 THERMISTOR ASSEMBLY 6323A20004K 6323A20004K 6323A20004K R

264110 POWER CORD ASSEMBLY 6411A20026D 6411A20026D 6411A20026A R

266090 H.V ASSEMBLY - - - R

267110 REMOTE CONTROLLER ASSEMBLY 6711A90023C 6711A90023C 6711A90023C R

268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A90476C 6871A90476C 6871A90476C R

268714-1 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20272R 6871A20272A 6871A20272A R

268714-2 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20310B 6871A20310G 6871A20309F R

342800 BEARING 4280A20004B 4280A20004B 4280A20004B R

346810 MOTOR ASSEMBLY,INDOOR 4681A20062N 4681A20062L 4681A20048R R

35211B TUBE ASSEMBLY,TUBING 5211A21046R 5211A21046R 5211A21046S R

352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F R

354212 EVAPORATOR ASSEMBLY,FIRST 5421A10024A 5421A10024A 5421A20086A R

359011 FAN ASSEMBLY,CROSS FLOW 5901A20007E 5901A20007E 5901A20007D R

733010 PLATE ASSEMBLY,INSTALL 3301A10003A 3301A10003A 1H00843A R

W0CZZ CAPACITOR,DRAWING 3H01487A 3H01487A 3H01487A R

W6640 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20283A 6871A20283A 6871A20283A R

AS-H076QGA2 AS-H096QGA2 AS-H126RGA2

NOTE)

Please ensure GCSC since these parts may be changed depending upon the buyer's request.

(GCSC WEBSITE http://biz.LGservice.com)
