Service Manual 63
Replacement Parts List
Parts List (Indoor)
LOCATION
DESCRIPTION
PART No.
REMARKS
No.
131410 CHASSIS ASSEMBLY 3141A20005A 3141A20005B 3141A20005A R
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10234P 3531A10234P 3531A10234P R
135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A21018B 3531A21017D 3531A21015G R
135314 GRILLE,INLET 3530A10079A 3530A10090A 3530A10128A R
135516 COVER ASSEMBLY,MOTOR 3551A20050A 3551A20050A 3551A20050A R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A R
152302 FILTER(MECH),A/C 5230A20014C 5230A20014B 5230A20014C R
152313 FILTER ASSEMBLY,DEODORIZER - 5231A20032E 5231A20032E R
159830 AIR CLEANER ASSEMBLY - - - R
159901 VANE,HORIZONTAL 5990A20007A 5990A20007A 5990A20007A R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20258B 4995A20258B 4995A20258B R
263230 THERMISTOR ASSEMBLY 6323A20004K 6323A20004K 6323A20004K R
264110 POWER CORD ASSEMBLY 6411A20026A 6411A20026A 6411A20026A R
266090 H.V ASSEMBLY - - - R
267110 REMOTE CONTROLLER ASSEMBLY 6711A90023C 6711A90023C 6711A20030S R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A90476C 6871A90476C 6871A90476C R
268714-1 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20272A 6871A20272A 6871A20272A R
268714-2 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20309F 6871A20309F 6871A20309F R
342800 BEARING 4280A20004B 4280A20004B 4280A20004B R
346810 MOTOR ASSEMBLY,INDOOR 4681A20048R 4681A20048R 4681A20048R R
35211B TUBE ASSEMBLY,TUBING 5211A21046S 5211A21046S 5211A21046S R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F R
354212 EVAPORATOR ASSEMBLY,FIRST 5421A20086A 5421A20086A 5421A20086A R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20007D 5901A20007D 5901A20007D R
733010 PLATE ASSEMBLY,INSTALL 1H00843A 1H00843A 1H00843A R
W0CZZ CAPACITOR,DRAWING 3H01487A 3H01487A 3H01487A R
W6640 PWB(PCB) ASSEMBLY,SUB 6871A20283A 6871A20283A 6871A20283A R
LS-H126RGA2 LS-H126RLA2 LS-H126RMA2
NOTE)
*
Please ensure GCSC since these parts may be changed depending upon the buyer's request.
(GCSC WEBSITE http://biz.LGservice.com)
