60 Room Air Conditioner
Troubleshooting Guide
Troubleshooting for error code
Description Cause of error
1
Indoor TH. (sensor) is short or open
Indoor TH. (sensor) is not connected to the indoor pcb assembly
Damage or defect on the sensing circuit of indoor pcb assembly.
(R01H, R02H, R03H, R04H, C01H, C02H)
Indoor TH. is short or
open
Indoor TH. is connected to
Indoor pcb
assembly ?
Indoor TH. is right ?
YES
No
- Connect to CN-TH1 in
indoor pcb assembly
Sensing circuit of indoor
pcb
is right ?
No
Check Indoor TH.
- Measure resistance of TH.
(air : about 10k at 25°C,
pipe : about 5k at 25°C)
YES
No
- Check soldering state of
R01H ~ R04H, C01H, C02H
Check flow
2
Outdoor TH. (sensor) is short or open
Outdoor TH. (sensor) is not connected to the outdoor pcb assembly
Damage or defect on the sensing circuit of outdoor pcb assembly.
(R03H~R06H, C02H, C03H)
Outdoor TH. is short or
open
Description
Error code
Error code
Cause of error
Outdoor TH. is connected to
outdoor pcb
assembly ?
Outdoor TH. is right ?
YES
No
- Connect to CN-TH1 in
outdoor pcb assembly
Sensing circuit of outdoor
pcb
is right ?
No
Check outdoor TH.
- Measure resistance of TH.
(air : about 10k at 25°C,
pipe : about 5k at 25°C)
YES
No
- Check soldering state of
R03H ~ R06H, C02H, C03H
Check flow
