Service Manual 83
Replacement Parts List
Replacement Parts List
Parts List (Indoor)
LOCATION
DESCRIPTION
PART No.
REMARKS
No.
131410 CHASSIS ASSEMBLY 3141A20019C 3141A20019C 3141A20020B
135311 GRILLE ASSEMBLY,DISCHARGE 3531A10307A 3531A10307A 3531A20252A
135312 GRILLE ASSEMBLY,FRONT 3531A14002D 3531A14002B 3531A20253K
135516 COVER ASSEMBLY,MOTOR 3551A20156A 3551A20156A 3551A20154A
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A
152302 FILTER(MECH),A/C 5230A20051A 5230A20051A 5230A20052B
159901 VANE,HORIZONTAL 5990A20048A 5990A20048A 5990A20049A
249951 CONTROL BOX ASSEMBLY 4995A20495B 4995A20495A 4995A20495C
263230 THERMISTOR ASSEMBLY 6323A20004A 6323A20004A 6323A20004A
264110 POWER CORD ASSEMBLY 6411A20013E 6411A20013E 6411A20014Z
266090 H.V ASSEMBLY 6609A10003Z 6609A10003Z -
267110 REMOTE CONTROLLER 6711A20077Y 6711A20077Y 6711A90032Y
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20574A 6871A20574A 6871A20624A
268714 PWB(PCB) ASSEMBLY 6871A20675A 6871A20156A 6871A20156B
342800 BEARING 4280A20004B 4280A20004B 4280A20004A
346810 MOTOR ASSEMBLY,INDOOR 4681A20151B 4681A20091J 4681A20091J
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20218A 5421A20218A 5421A20220A
359011 FAN ASSEMBLY,CROSS FLOW 5901A20017F 5901A20017F 5901AR2441E
733010 PLATE ASSEMBLY,INSTALL 3301A20011A 3301A20011A 3301A20002B
35211B TUBE ASSEMBLY,TUBING 5211A21363A 5211A21363B 5211A21378C
W0CZZ CAPACITOR,DRAWING 3H01487K -
152313 FILTER ASSEMBLY DEODORIZER 5231A20040A 5231A20040A 5231A20040A
152510 HOSE ASSEMBLY,DRAIN 5251A20011D 5251A20011D 5251A20011D
AS-W0964DH0 AS-W1264DH0 AS-W1865DH0
NOTE)
*
Please ensure GCSC since these parts may be changed depending upon the buyer's request.
(GCSC WEBSITE http://biz.LGservice.com)
To Next Page
