84 Room Air Conditioner

Replacement Parts List

Parts List (Indoor)

LOCATION

DESCRIPTION

PART No.

REMARKS

No.

131410 CHASSIS ASSEMBLY 3141A20019C 3141A20019C 3141A20019C 3141A20019E 3141A20020B

135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10307A 3531A10307A 3531A10307J 3531A10307P 3531A20252H

135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A14003C 3531A14003D 3531A14002R 3531A14002R 3531A20253S

135314 GRILLE ASSEMBLY,INLET 3531A10339B 3531A10339B 3531A10312D 3531A10312D 3531A20254E

135516 COVER ASSEMBLY,MOTOR 3551A20156B 3551A20156B 3551A20156B 3551A20156B 3551A20154A

146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A 4681A20055A 4681A20055A

152302 FILTER(MECH),A/C 5230A20051A 5230A20051A 5230A20051A 5230A20051A -

159901 VANE,HORIZONTAL 5990A20048A 5990A20048A 5990A20048A 5990A20048A 5990A20049A

249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20495B 4995A20495A 4995A20495E 4995A20495F 4995A20495D

263230 THERMISTOR ASSEMBLY 6323A20004A 6323A20004A 6323A20004A 6323A20004A 6323A20004A

264110 POWER CORD ASSEMBLY 6411A20013E 6411A20013E 6410A20007E 6410A20007E 6410A20007F

266090 H.V ASSEMBLY 6609A10003Z 6609A10003Z 6609A10003Z 6609A10003Z 6609A10003Z

267110 REMOTE CONTROLLER ASSEMBLY 6711A20077Y 6711A20077Y 6711A20124A 6711A20124A 6711A20124A

268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20574A 6871A20574A 6871A20574A 6871A20574A 6871A20624A

268714 PWB(PCB) ASSEMBLY,MAIN 6871A20675A 6871A20156A 6871A20156D 6871A20156C 6871A20156B

342800 BEARING 4280A20004B 4280A20004B 4280A20004B 4280A20004B 4280A20004A

346810 MOTOR ASSEMBLY,INDOOR 4681A20151B 4681A20091J 4681A20091J 4681A20091J 4681A20091J

354210 EVAPORATOR ASSEMBLY,FIRST 5421A20218A 5421A20218A 5421A20218A 5421A20218A 5421A20220A

359011 FAN ASSEMBLY,CROSS FLOW 5901A20017F 5901A20017F 5901A20017F 5901A20017F 5901AR2441E

733010 PLATE ASSEMBLY,INSTALL 3301A20011A 3301A20011A 3301A20011A 3301A20011A 3301A20002A

35211B TUBE ASSEMBLY,TUBING 5211A21363A 5211A21363B 5211A21363B 5211A21363B 5211A21378C

W0CZZ CAPACITOR,DRAWING 3H01487K - - - -

AS-W0964GH0 AS-W1264GH0 AS-W1224DH0 AS-W1424DH0 AS-W1825DH0

NOTE)

Please ensure GCSC since these parts may be changed depending upon the buyer's request.

(GCSC WEBSITE http://biz.LGservice.com)
