Service Manual 85

Replacement Parts List

Parts List (Indoor)

LOCATION

DESCRIPTION

PART No.

REMARKS

No.

352150 Hose Assembly,Drain 5251A20011G 5251A20011G R

733010 Plate Assembly,Installation 3301A20020A 3301A20020A R

135311 Grille Assembly,Discharge(Indoor) 3531A10362A 3531A10362A R

159901 Louver,Horizontal 5990A20068A 5990A20068A R

146811 Motor Assembly,DC,Stepping 4681A20055A 4681A20055A R

268712 PCB Assembly,Display 6871A20574A 6871A20574A R

135312 Grille Assembly,Front(Indoor) 3531A18013B 3531A18015E R

152302 Filter,Air 5230A20064A 5230A20064A R

249951 Case Assembly,Control(Indoor) 4995A20495S 4995A20495Q R

268714 PCB Assembly,Main 6871A20156Q 6871A20156P R

264110 Power Cord 6411A20013E 6411A20013E R

263230-1 Thermistor,NTC 6323A20004A 6323A20004A R

266090 HVPS,DC/DC 6609A10003Z 6609A10003Z R

354210 Evaporator Assembly,First 5421A20258B 5421A20258B R

35211B Tube Assembly,Tubing 5211A29044A 5211A29044A R

359011 Fan Assembly,Cross Flow 5901A20017H 5901A20017H R

342800 Bearing 4280A20004B 4280A20004A R

135516 Cover Assembly,Motor 3551A20156B 3551A20156B R

346810 Motor Assembly,DC 4681A20091J 4681A20091J R

267110 Remote Controller Assembly 6711A20073U 6711A20096Q R

131410 Chassis Assembly 3141A20034A 3141A20034A R

159830 Filter Assembly,Air Cleaner 5983A20017F 5983A20017L R

152313 Filter Assembly,Deodorizer - 5231A20040K R

AS-W096E1G0 AS-W126E1G0

NOTE)

Please ensure GCSC since these parts may be changed depending upon the buyer's request.

(GCSC WEBSITE http://biz.LGservice.com)
