Service Manual 87

Replacement Parts List

Parts List (Outdoor)

263230-1 THERMISTOR ASSEMBLY 6323A20001C 6323A20001C 6323A20001C 6323A20001C 6323A20001B

263230-2 THERMISTOR ASSEMBLY 6323A20003G 6323A20003G 6323A20003G 6323A20003G 6323A20003C

430410 BASE ASSEMBLY,OUTDOOR 3041A20066A 3041A20066A 3041A20066A 3041A20066A 3041A20022Q

435301 GRILLE,DISCHARGE 3530A20006G 3530A20006G 3530A20006G 3530A20006G 3530A20007B

435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3551A30115G 3551A30115G 3551A30115G 3551A30115G 3551A30102A

437210 PANEL ASSEMBLY,FRONT(OUTDOOR) 3721A20027Q 3721A20027Q 3721A20027Q 3721A20027Q 3721A20005H

437212 PANEL ASSEMBLY,REAR(OUTDOOR) 3721A20026M 3721A20026M 3721A20026M 3721A20026M 3720AP0003D

447910 BARRIER ASSEMBLY,OUTDOOR 4791A30002G 4791A30002G 4791A30002G 4791A30002G 2H02110G

546810 MOTOR ASSEMBLY,OUTDOOR 4681A20068G 4681A20122A 4681A20122A 4681A20122A 4681A20028L

550140 ISOLATOR,COMP 4984AR4387A 4H00982E 4H00982E 4H00982E 4H00982E

552102-1 TUBE,CAPILLARY BEND 5210A21447M 5210A21447E 5210A21447E 5210A21447E 5210A31380D

552102-2 TUBE,CAPILLARY BEND 5210A33068B 5210A33068A 5210A33068A 5210A33068A 5210A31380E

552111 TUBE ASSEMBLY,CAPILLARY 5211A21393C 5211A21393B 5211A21393B 5211A21393E -

552116 TUBE ASSEMBLY,REVERSING 5211A10466B 5211A10466C 5211A10466C 5211A10466D 5211A21140B

552201 VALVE,CHECK 3H01552F 3H01552F 3H01552F 3H01552F 5220A30004A

552202 VALVE,REVERSING 5220AR3228D 5220AR3228D 5220AR3228D 5220AR3228D 5220AR3228E

554031 CONDENSER ASSEMBLY,BENT 5403A20019V 5403A20019V 5403A20019V 5403A20019V 5403A21012B

554160 COMPRESSOR 5416A90045A 5416A90029A 5416A90029A 5416A90029A 5416A90024A

559010 FAN ASSEMBLY,PROPELLER 5901A10033A 5901A10033A 5901A10033A 5901A10033A 1A00195B

561410 COIL ASSEMBLY,REVERSING VALVE 6141A20010S 6141A20010S 6141A20010S 6141A20010S 6141A20010H

649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A21006H 4995A21006J 4995A21006M 4995A21006N 4995A20346H

552203-1 VALVE,SERVICE 5220A20005B 5220A20005B 5220A20005B 5220A20005B 5220A20006A

552203-2 VALVE,SERVICE 5220A20001Q 5220A20006F 5220A20006F 5220A20006F 2H02479F

668711 PWB(PCB) ASSEMBLY, MAIN 6871A10128P 6871A10128Q 6871A10128U 6871A10128V 3871A20349G

W0CZZ CAPACITOR,DRAWING 0CZZA90002M 0CZZA90002N 0CZZA90002N 0CZZA90002N 0CZZA90002N

LOCATION

DESCRIPTION

PART No.

REMARKS

No.

AS-W0964GH0 AS-W1264GH0 AS-W1224DH0 AS-W1424DH0 AS-W1825DH0

NOTE)

Please ensure GCSC since these parts may be changed depending upon the buyer's request.

(GCSC WEBSITE http://biz.LGservice.com)
