9. Electric Characteristics
95
Single CAC Outdoor Unit
Standard Inverter
AUUW426D2
[UU42W U32]
ATNH42GMLE2
[UT42 NM2]
1
1 50
220-240
Min. : 198
Max. : 264
24.6 40 - 18.08 0.248 0.95 0.210 1.00
ABNW42GM2A0
[UM42 N24]
25.1 40 - 18.08 0.248 0.95 0.260 1.50
UVNH42GLLA2
[UV42 NL2]
24.6 40 - 18.08 0.248 0.95 0.130 1.00
AUUW486D2
[UUW48 U32]
ATNH48GMLE2
[UT48 NM2]
28.8 40 - 21.51 0.248 0.95 0.210 1.00
ABNW48GM3A0
[UM48 N34]
28.9 40 - 21.51 0.248 0.95 0.180 1.10
UVNH48GLLA2
[UV48 NL2]
28.9 40 - 21.51 0.248 0.95 0.140 1.10
APNH48GTLA0
[UP48 NT2]
28.7 40 - 21.51 0.248 0.95 0.150 0.90
AUUW606D2
[UU60W U32]
ATNH60GMLE2
[UT60 NM2]
33.9 40 - 25.57 0.248 0.95 0.210 1.00
ABNW60GM3A0
[UM60 N34]
34.6 40 - 25.57 0.248 0.95 0.290 1.65
UVNH60GLLA2
[UV60 NL2]
34.1 40 - 25.57 0.248 0.95 0.150 1.20
AUUW368D2
[UU37W UO2]
ATNH36GNLE2
[UT36 NN2]
3 50
318-415
Min. : 342
Max. : 456
10.9 20 - 7.71 0.171 0.65 0.140 0.60
ABNW36GM2A0
[UM36 N24]
11.6 20 - 7.71 0.171 0.65 0.210 1.30
UVNH36GKLA2
[UV36 NK2]
11.0 20 - 7.71 0.171 0.65 0.090 0.70
AJNW36GVLA1
[UJ36 NV3]
10.9 20 - 7.71 0.171 0.65 0.160 0.60
AUUW428D2
[UU43W U32]
ATNH42GMLE2
[UT42 NM2]
12.5 20 - 8.47 0.248 0.95 0.210 1.00
ABNW42GM2A0
[UM42 N24]
13.0 20 - 8.47 0.248 0.95 0.260 1.50
UVNH42GLLA2
[UV42 NL2]
12.5 20 - 8.47 0.248 0.95 0.130 1.00
AUUW488D2
[UU49W U32]
ATNH48GMLE2
[UT48 NM2]
13.4 20 - 9.12 0.248 0.95 0.210 1.00
ABNW48GM3A0
[UM48 N34]
13.5 20 - 9.12 0.248 0.95 0.180 1.10
UVNH48GLLA2
[UV48 NL2]
13.5 20 - 9.12 0.248 0.95 0.140 1.10
APNH48GTLA0
[UP48 NT2]
13.3 20 - 9.12 0.248 0.95 0.150 0.90
AUUW608D2
[UU61W U32]
ATNH60GMLE2
[UT60 NM2]
14.4 20 - 9.97 0.248 0.95 0.210 1.00
ABNW60GM3A0
[UM60 N34]
15.1 20 - 9.97 0.248 0.95 0.290 1.65
UVNH60GLLA2
[UV60 NL2]
14.6 20 - 9.97 0.248 0.95 0.150 1.20
AUUW70LAE
[UU70W U34]
ABNW70GB9A0
[UB70 N94]
18.3 30 - 11.5 0.248 0.95 - 3.00
AUUW80LAE
[UU85W U74]
ABNW85GB9A0
[UB85 N94]
22.8
30 - 13.6 0.850 2.80 - 3.00
Outdoor Unit Combined Indoor Unit Unit Power Comp OFM IFM
Model names Model Name
No. of
Unit
Phase
Hz
Volts
Voltage
range
MCA MFA MSC RLA kW FLA kW FLA
Note
1. Voltage supplied to the unit terminals should be within the minimum and
maximum range.
2. Maximum allowable voltage unbalance between phase is 2%.
3. MSC means the Max. current during the starting of compressor.
4. MSC and RLA are measured as the compressor only test condition.
5. OFM and IFM are measured as the outdoor unit test condition.
6. Select the wire size based on the MCA.
7. MFA is used to select the circuit breaker and ground fault circuit
interrupter, and recommended circuit breaker type is ELCB(Earth Leakage
Circuit Breaker).
MCA : Minimum Circuit Amperes (A)
MFA : Maximum Fuse Amperes (A)
MSC : Maximum Starting Current
RLA : Rated Load Amperes (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
kW : Fan Motor rated output (kW)
FLA : Full Load Amperes (A)
