5. DOWNLOAD AND CALIBRATION
- 95 -
1. Connect as Fig 6-2(RS232 serial cable is connected between COM port of PC and MON port
of TEST JIG, in general)
2. Set the Power Supply 4.0V
3. Set the 3rd, 4thof DIP SW ON state always
4. Press the Phone power key, if the Remote ON is used, 1stON state
D. Procedure
1. Connect as Fig 6-2(RS232 serial cable is connected between COM port of PC and MON port
of TEST JIG, in general)
2. Power ON PC then enter into Windows 98(Remark : Windows 2000 system could be feasible)
3. Run AUTOCAL.exe, the AUTOCAL application window will be appeared.
To Next Page
