RS-232C
36
03. Screen Mute (Command:kd)
‹ To select screen mute on/off.
Transmission
Data 0 : Screen Mute Off (Picture On)
1 : Screen Mute On (Picture Off)
Data 0 : Screen Mute Off (Picture On)
1 : Screen Mute On (Picture Off)
[k] [d] [ ] [Set ID] [ ] [Data] [Cr]
[d] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
06. Color (Command:ki)
‹ To adjust the screen color. (Video/Component)
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 1’.
Data Min : 0 ~ Max : 64
[k] [ i ] [ ] [Set ID] [ ] [Data] [Cr]
[ i ] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
07. Tint (Command:kj)
‹ To adjust the screen tint.(Video/Component 60Hz or
NTSC signal)
Transmission
Data Red : 0 ~ Green : 64
*
Refer to ‘Real data mapping2’.
Data Red : 0 ~ Green : 64
[k] [ j ] [ ] [Set ID] [ ] [Data] [Cr]
[ j ] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
08. Sharpness (Command:kk)
‹ To adjust the screen sharpness.(Video/Component)
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 1’.
Data Min : 0 ~ Max : 64
[k] [k] [ ] [Set ID] [ ] [Data] [Cr]
[k] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
09. OSD Select (Command:kl)
‹ To select OSD On/Off.
Transmission
Data 0 : OSD Select Mode Off
1 : OSD Select Mode On
Data 0 : OSD Select Mode Off
1 : OSD Select Mode On
[k] [ l ] [ ] [Set ID] [ ] [Data] [Cr]
[ l ] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
10. Remote Control Lock/Key Lock
(Command:km)
‹ To lock the front panel controls on the
projector and remote control.
Transmission
Data 0 : Lock Off
1 : Lock On
Data 0 : Lock Off
1 : Lock On
[k] [m] [ ] [Set ID] [ ] [Data] [Cr]
[m] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
* If you're not using the remote control, use this mode.
When main power is On/Off, external control lock is released.
11. Color Temperature (Command:ku)
‹ Adjust the color temperature.
Transmission
Data 0 : Normal 1 : Cool 2:Warm 3 : Natural
Data 0 : Normal 1 : Cool 2:Warm 3 : Natural
[k] [u] [ ] [Set ID] [ ] [Data] [Cr]
[u] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
04. Contrast (Command:kg)
‹ To adjust screen contrast.
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 1’.
Data Min : 0 ~ Max : 64
[k] [g] [ ] [Set ID] [ ] [Data] [Cr]
[g] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
05. Brightness (Command:kh)
‹ To adjust screen brightness.
Transmission
Data Min : 0 ~ Max : 64
*
Refer to ‘Real data mapping 1’.
Data Min : 0 ~ Max : 64
[k] [h] [ ] [Set ID] [ ] [Data] [Cr]
[h] [ ] [Set ID] [ ] [OK] [Data] [x]
Ack
