LG CM2760 Simple Manual

Speaker Connection
Red
Black
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
MICRO HI-FI SYSTEM is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
Additional Information
Specifications
Power Requirements
Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions (W x H x D)
Approx. 170 mm x
230 mm x 276 mm
Net Weight
Approx. 2.2 kg
Bus Power Supply (USB)
5 V 0 500 mA
Amplier
(Total RMS output power)
160 W
Design and specications are subject to change without
notice.
CM2760-DB_AWEULLZ_SIM_ENG_1511.indd 3 2017-04-20  11:37:12

LG CM2760 Specifications

General

Type	Home audio micro system
Product color	Black
Optical disc player	No
Impedance	4 Ω
Speaker type	2-way
Frequency range	80 - 20000 Hz
RMS rated power	160 W
Number of speakers	2
Built-in speaker(s)	-
Signal-to-Noise Ratio (SNR)	80 dB
Total Harmonic Distortion (THD)	10 %
Supported radio bands	FM
Radio Data System (RDS)	Yes
Display type	LCD
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Apple docking compatibility	iPad, iPhone, iPod
Audio formats supported	FLAC, MP3, WAV
Equalizer modes	Classic, Jazz, Pop, Rock
Power source	AC
Input voltage	220-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	45 W

Weight and Dimensions

Main unit weight	2200 g
Main unit dimensions (WxDxH)	170 x 230 x 276 mm
