Appendix32
Appendix
5
Main unit
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D)
Approx. 272 mm x 336 mm x 393 mm
(Approx 10.7 inch x 13.2 inch x 15.4 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs
Analog audio in (AUX IN) 2.0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R) x 1
Portable in (PORT. IN) 1.8 Vrms (3.5 mm stereo jack) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz
System
Frequency response 60 to 20,000 Hz
Signal-to-noise ratio 80 dB
Dynamic range 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total 200 W RMS
Front 100 W RMS X 2 (4 Ω at 1 kHz, 10 % THD)
