POWER ON
FLD no disc status or AUX status.
Remote control ‘Fwd skip’ + Front ‘STOP’ push same
timing during 5 seconds.
FLD ‘OP-0….
Move to appropriate position and make changes with
remote control ‘skip, mode, play’ key.
Press ENTER key
FLD ‘write ok’
Remote control ‘Fwd skip’ +
Front ‘STOP’ push same timing
FLD ‘E2P CLR’
Completed
1-7
SERVICE INFORMATION FOR EEPROM
7
9
Table of Contents
Section 1 Summary
3
Default Chapter
3
Table of Contents
3
Servicing Precautions
4
Esd Precautions
6
Hidden Key Mode
7
Service Information for Eeprom
8
1 Mcs Program
9
Program Download & Update Guide
9
2 Eq Program
10
Specifications
11
Section 2 Cabinet & Main Chassis
12
Exploded Views
14
Cabinet and Main Frame Section (Cm4550)
14
Mechanism Deck Section (Dp17Tm3)
15
Packing Accessory Section
16
Speaker Section
17
Section 3 Electrical
20
One Point Repair Guide
21
No Power
21
One Point Repair Guide
22
No Booting When Power on the Set
23
Vfd Is Not Displayed When Power on the Set
24
No Operation of MD
26
No Sound
31
Audio Electrical Troubleshooting Guide
36
Power (Smps)
36
Mcs Part Check
39
Ic504(M24C16) Check
39
Fld Display Check
40
Pwm Modulation Check
41
Power Amp Part Check
43
Tuner / Aux Function Check
44
Tuner Function Check
45
Cdp Electrical Troubleshooting Guide
46
CD Function
46
Double Usb Function
47
Waveforms of Major Check Point
48
Sdram
48
Servo
48
Audio Path
49
Usb
50
Wiring Diagram
52
Block Diagrams
53
System Block Diagram
53
Smps Block Diagram
54
Block Diagrams
54
Audio Path Block Diagram
55
Amp Block
55
Power Diagram
56
Circuit Diagrams
57
Smps Circuit Diagram
57
Main - Dsp Circuit Diagram
58
Main - Servo Circuit Diagram
59
Main - Adc/ Pwm Circuit Diagram
60
Main - Amp Circuit Diagram
61
Front Circuit Diagram
62
Circuit Voltage Chart
63
Ics
63
Capacitors
64
Printed Circuit Board Diagrams
65
Smps P.C.board
65
Main P.C.board
66
Front P.C.board
67
Appendix Mechanism (Dp17Tm3)
68
Appendix
69
Clamp Assembly
69
Plate
69
Magnet
69
Clamp
69
Cover Top
69
Tray Disc
70
Base Up/Down
71
Pick up Assembly
71
Belt Loading
72
Deck PCB Assembly
72
FFC Cable
72
Gear Loading
72
Gear Pulley
72
Guide
72
Motor Assembly
72
Deck Mechanism Disassembly
69
Deck Mechanism Exploded View (Dp17Tm3)
73
