PRODUCT INTRODUCTION
ENGLISH
Name and function of parts (4-WAY CEILING CASSETTE)
Name and function of parts (CELING CONCEALED DUCT)
3
7
2
8
6
1
5
4
4
1: Indoor unit
2: Outdoor unit
3: Remote controller
4: Inlet air
5: Discharge air
6: Refrigerant piping, connection electric wire
7: Drain pipe
8: Ground wire
Wire to ground outdoor unit to prevent electrical
shocks.
4
2
8
4
5
Remote
Controller
3
Air intake
vents
1
Air outlet
vents
6
7
1: Indoor unit
2: Outdoor unit
3: Remote controller
4: Inlet air
5: Discharge air
6: Refrigerant piping, connection electric wire
7: Drain pipe
8: Ground wire
wire to ground outdoor unit to prevent electrical
shocks.
