Part 2 Functions & Controls
Ceiling Concealed Duct – Low static
- The above table shows the correlation between the air flow rate and E.SP.
- Be sure to set the value by referring to the table above. Incorrect setting values can cause malfunction.
- The values in the table are based on electrical rated conditions. Therefore, if there is a fluctuation in voltage,
the air flow rate may change.
Chassis
Capacity
[kBtu/h]
Grade Step CMM
Static Pressure [mmAq(Pa)]
0(0) 1(10) 2(20) 3(29) 4(39) 5(49)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06
L5 9
Standard
Compact
LOW 8 76 87 96 106 116 116
MID 9.5 87 96 106 114 120 120
HIGH 11.5 101 109 118 125 130 130
L5 12
Standard
Compact
LOW 8 76 87 96 106 116 116
MID 9.5 87 96 106 114 120 120
HIGH 11.5 101 109 118 125 130 130
L6 18
Standard
Compact
LOW 10 82 87 90 96 106 116
MID 12.5 92 98 105 109 119 128
HIGH 15 100 106 112 122 129 137
L3 24
Standard
Compact
LOW 12 89 95 102 106 120 130
MID 16 102 108 115 125 131 139
HIGH 20 125 131 136 141 142 147
L5 12 High
LOW 8 76 87 96 106 116 116
MID 9.5 87 96 106 114 120 120
HIGH 11.5 101 109 118 125 130 130
L3 18 High
LOW 10 80 90 95 100 110 120
MID 14 97 103 109 117 126 134
HIGH 18 115 122 127 133 138 142
