Part 2 Functions & Controls
Ceiling Concealed Duct – Mid static(1)
- The above table shows the correlation between the air flow rate and E.SP.
- Be sure to set the value by referring to the table above. Incorrect setting values can cause malfunction.
- The values in the table are based on electrical rated conditions. Therefore, if there is a fluctuation in voltage,
the air flow rate may change.
Chassis
Capacity
[kBtu/h]
Grade Step CMM
Static Pressure [mmAq(Pa)]
2(20) 2.5(25) 3(29) 4(39) 6(59) 8(78) 10(98) 12(118) 13(127) 14(137) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
M1 18
Standard
Compact
LOW 13 73 74 77 88 93 103 111 117 120 125 128
MID 14.5 76 77 86 91 97 107 114 121 125 128 131
HIGH 16.5 86 87 90 94 103 110 118 125 128 131 134
M1 24
Standard
Compact
LOW 14.5 76 77 86 89 97 106 114 121 124 127 130
MID 16.5 86 87 90 94 103 111 118 125 128 131 134
HIGH 18 90 92 95 99 108 115 122 129 132 135 138
M1 12 High
LOW 9 64 67 70 72 81 94 103 110 113 117 121
MID 12 68 72 74 76 86 100 108 115 118 121 125
HIGH 16 81 86 89 93 98 110 118 124 127 131 135
M1 18 High
LOW 14 76 77 86 89 97 107 114 121 124 127 130
MID 16 86 87 90 94 103 111 118 125 128 131 134
HIGH 17.5 90 92 95 99 108 115 122 129 132 135 138
Chassis
Capacity
[kBtu/h]
Grade¡ Step CMM
Static Pressure [mmAq(Pa)]
2.5(25) 4(39) 5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
M1 30
Standard
Compact
LOW 18 96 102 107 110 114 118 122 125 127 130 132
MID 20 102 110 114 118 121 125 127 130 133 134 136
HIGH 22 110 117 121 124 127 130 133 136 137 138 140
M2 24 High
LOW 21 84 88 89 90 95 96 100 105 110 112 113
MID 24 88 92 94 95 100 101 108 113 118 118 118
HIGH 28 92 96 99 101 105 108 115 118 124 124 124
M2 30 High
LOW 21 84 88 89 90 95 96 100 105 110 112 113
MID 24 88 92 94 95 100 101 108 113 118 118 118
HIGH 28 92 96 99 101 105 108 115 118 124 124 124
