15
INSTALLATION
ENGLISH
Attaching the Strip to the
Appliance Side Cabinet
To reduce noise attach the strip to the appliance
sides, if the opening space allows.
1
Remove the double-side tape from the side
strips.
2
Attach the side strip to the front of the side
cabinet and then push down the side strip so
that the side strip adheres well to the cabinet.
3
Repeat the above steps for attaching the
opposite side strip to the opposite side cabinet.
Removing the Top Cover
If the height of the opening is below 850 mm,
follow these instructions.
1
Remove the 2 screws on the back.
2
Pull the top cover backwards after removing
the two screws and then lift it up to remove it.
3
Remove the locating pins on the top by using a
Phillips screw driver.
• When the appliance is correctly leveled, there
should be no slant, stickiness or rubbing sound
when the door is opened.
Installing Moisture Barrier Tape
When the appliance is installed without the top
cover, the counter top underside may be damaged
by steam or condensation when the door is
opened.
To Next Page
