OWNER’S MANUAL
WASHING MACHINE
WM0642H*
P/NO : MFL31245123
www.lge.com
Please read this manual carefully before operating
your set and retain it for future reference.
DISHWASHER
OWNER'S MANUAL
Please read this manual carefully before operating
your dishwasher. Retain it for future reference.
D1417W(L,M,T,B,C,D)F(B,U)
D1418W(L,M,T,B,C,D)F(B,U)
D1419W(L,M,T,B,C,D)F(B,U)
WZ-6809WF / WZ-6809MF
WZ-6810WF
P/No. : MFL62077155

Table of Contents

Other manuals for LG D1417 Series

Preview: Service Manual
Service Manual44 pages

Questions and Answers

  • S
    Samuel DayAug 14, 2025
    What to do if my LG Dishwasher displays DRAIN ERROR?
    • K
      Karen HallAug 14, 2025
      If your LG Dishwasher displays a DRAIN ERROR, it could be due to several reasons. The filter might be clogged, so try cleaning it. Alternatively, the drain hose could be kinked or blocked; in this case, remove whatever is causing the kink or blockage. If neither of these solutions works, the drain pump/motor or its circuit may be faulty, requiring you to replace the drain pump/motor or repair the circuit.
  • C
    connietateAug 17, 2025
    Why do no lights come on when I turn on my LG Dishwasher?
    • J
      Jordan WareAug 17, 2025
      If no lights appear when you turn on your LG Dishwasher, check the plug and the electricity supply. If both are fine, call for service.
  • M
    Michelle JordanAug 20, 2025
    How to fix INLET ERROR on my LG D1417 Dishwasher?
    • R
      Ryan MathisAug 20, 2025
      If your LG Dishwasher displays an INLET ERROR, there are several potential causes. First, make sure the water tap is fully opened. If it is, check the inlet hose for any kinks and repair them. Another possibility is that the filter of the inlet valve is clogged by impure water; in this case, close the water tap, unscrew the inlet hose (at the inlet valve side), and clean the filter. If the inlet water valve itself might be faulty, consider replacing or repairing it. Also, verify that the water pressure isn't too low (below 0.5 kgf/). Finally, the inlet valve could be blocked by a safety device due to leakage sensing; if this is the case, check for damages, repair or replace the related parts, and disconnect the inlet hose to the dishwasher to unlock the safety valve.
  • J
    Julie WhiteAug 25, 2025
    Why does my LG D1417 Dishwasher display LEAKAGE ERROR?
    • M
      mwoodsAug 25, 2025
      If your LG Dishwasher shows a LEAKAGE ERROR, it could be due to a few reasons. There might be water leakage in the hose connections, in which case you should replace the hose connections. Water could also be leaking due to damage; inspect for any damage and repair or replace the affected parts. Additionally, the impeller of the washing pump might be worn away, requiring you to replace the washing pump. Lastly, the thermal protector of the washing motor could be activated, so check the applied voltage.
  • J
    Jennifer HerreraAug 27, 2025
    What to do if my LG D1417 Dishwasher shows the "OE" code?
    • K
      kerry42Aug 27, 2025
      If your LG Dishwasher displays the "OE" code, it means the water is not being pumped away. Try these solutions: - Check the drain hose for any kinks and straighten them out. - Clean the filter to remove any clogs. If the problem persists, it may be a motor issue, and you should call for service.
  • A
    Angela JonesAug 30, 2025
    Why are there white deposits on my LG Dishwasher after washing?
    • A
      Anthony RuizAug 31, 2025
      White deposits after washing in your LG Dishwasher may be due to: incorrect detergent or rinse-aid settings (check them), an empty salt container (check and refill if needed), or a salt container cap that isn't securely screwed on (ensure it's tight).
  • K
    kbradfordSep 3, 2025
    Why does my LG Dishwasher display the "IE" code?
    • S
      Stephen McclureSep 3, 2025
      The "IE" code on your LG Dishwasher indicates a water supply issue. First, check that the water tap is open. If the problem persists, it could be a water sensor issue, and you should call for service.
  • R
    rebeccamillerSep 6, 2025
    What does the "EI" code mean on my LG D1417 Dishwasher?
    • J
      Joshua FordSep 6, 2025
      The "EI" code on your LG Dishwasher means the drain pump is operating automatically, likely due to a water leak. Close the water tap and unplug the power. If the issue persists, it could indicate damage from a water leak, and you should call for service.
  • C
    chandlermelissaSep 9, 2025
    Why don't the spray arms rotate smoothly in my LG D1417 Dishwasher?
    • M
      Michael KingSep 10, 2025
      If the spray arms in your LG Dishwasher aren't rotating smoothly, it might be because food particles are blocking their mounting. Clean the holes of the spray arms to resolve this.

Summary

Safety and Caution

Important Safety Instructions

General safety precautions for using the dishwasher, including warnings for installation, use, and child safety.

Power Cord, Grounding, and Disposal Precautions

Precautions regarding the power cord, grounding, and environmentally sound disposal of old appliances.

User Capability and Supervision Guidelines

Instructions for use by persons with reduced capabilities and supervision requirements for children.

Installation Instructions

Cupboard Opening and Electrical Preparation

Instructions for preparing the cupboard opening and electrical wiring connections, including safety warnings.

Dishwasher Preparation and Installation

Steps to prepare the dishwasher for installation and slide it into the prepared cupboard opening.

Water Supply, Leveling, and Final Checks

Guidance on water supply connection, final checks, assembly, and leveling the dishwasher for proper operation.

Parts Identification

Dishwasher Components Overview

Identification and description of various parts of the dishwasher, including racks, spray arms, and control panel.

Control Button Functions

Model-Specific Button Layouts

Explains the function of control buttons for different dishwasher models listed.

Indicator Lights and Their Meanings

Explains the indicators for wash phases, refill needs, Child Lock, and Extra Hot settings.

Operational Functions and Settings

Describes functions like Half Load, Delay Start, Beep On/Off, and Power for operating the dishwasher.

Before Using for the First Time

Water Hardness Setting

Guide on checking water hardness and setting the dishwasher's softening system level.

Salt and Rinse Aid Filling Procedures

Instructions on how to fill the water softener with salt and the rinse aid chamber.

How to Use and Operate

Dishwasher Loading Guidelines

General guidelines for loading dishes, cleaning food particles, and positioning for proper drying.

Rack and Cutlery Loading

Instructions for loading the lower rack, cutlery basket, and upper rack, including adjustments.

Detergent and Refill Procedures

Guidance on adding detergent and instructions for refilling rinse aid and salt.

Drying and Energy Test

Recommends opening the door for drying and details the standard energy test conditions.

Operating Sequence

Step-by-Step Operation Guide

A sequence of steps from powering on to starting a program, including checks and loading.

Program Completion and Indicators

What happens when the program finishes, including display messages and automatic shut-off.

Program Details

Dishwasher Program Descriptions

Explains the different wash programs and their characteristics.

Auto Restart Function

Describes the Auto Restart function after a power failure.

User Maintenance Instructions

Cleaning Filters and Spray Arms

Instructions on how to clean the dishwasher's filters and spray arms.

Troubleshooting Guide

Common Issues and Solutions

Lists common problems like no lights, machine not starting, and poor washing results with solutions.

Error and Status Codes Explanation

Explains error codes (OE, IE, etc.) and status codes (PF, Cd, CL, F) displayed by the dishwasher.

Specifications

Technical Specifications

Details dimensions, capacity, power supply, and water pressure requirements.
