Stacking kit installation (cont.)
3. Place the dryer on top of the washer by fitting the
dryer feet into the side brackets as illustrated. Avoid
finger injuries; do not allow fingers to be pinched
between the washer and dryer.
Slowly slide the dryer toward the back of the washer
until the side bracket stoppers catch the dryer feet.
4. Insert the front rail between the bottom of the dryer
and the top of the washer. Push the front rail toward
the back of the washer until it comes in contact with
the side rail stoppers.
Install the two remaining screws to secure the front
rail to the side rails.
Washer
Dryer
OPTIONAL ACCESSORIES
