4. Insert the two decorative screws on the right side.
5. Check that the door closes and latches properly.
1. Move the door to the left side and line up the holes in
the hinge with the holes in the cabinet.
2. Hold the hinge in place while inserting the two hinge
screws (to prevent the door from dropping).
3. Insert the latch on the right side and install the latch
screws.
Reversing the door (cont.)
w
WARNING
THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure
to follow the instructions below can result in damage
to the dryer, property damage or injury to persons.
the door.
INSTALLATION INSTRUCTIONS
Latch
Screw
Hinge Screw
Decorative
Hinge
Screw
Swing Door
Hinge hole
CAUTION
Be sure to support the weight of the door before
replacing the hinge screws.
To Next Page
