51
COVER CABINET
1.
Disassemble the top plate.
2.
Disassemble the control panel assembly.
3.
Disassemble the door assembly.
4.
Remove 2 screws.
5.
Remove 3 screws from the top of cabinet cover.
6.
Disconnect the harness of door switch.
WARNING !
When you disassemble the door switch connector,
be sure to disconnect the dryer from its electrical
supply. Protect your hands and arms from sharp
edges when working. To reduce the risk of Injury to
persons adhere to all industry recommended safety
procedures including the use of long sleeved gloves
and safety glasses.
PANEL FRAME
1.
Remove 2 screws on the panel frame
and then remove it
.
To Next Page
