16 INSTALLATION
Reversing the Door
(DLEX4500*, DLGX4501*)
WARNING
THE DRYER DOOR IS VERY LARGE AND
HEAVY. Failure to follow the instructions
below can result in damage to the dryer,
property damage or injury to persons.
To avoid damage to the dryer or the door,
support the door with a stool or box that fits
under the door, or have an assistant support
the weight of the door.
Always reverse the door BEFORE stacking
the dryer on top of the washer.
Avoid dropping the door to avoid damage to
the door or the floor.
1
Open the dryer door.
Open Door
2
You will be removing the screws shown below
(6 on left, 4 on right).
3
Remove the four decorative screws on the left
using a screwdriver.
Decorative
Hinge
Screw
4
Remove the two latch screws and the latch.
Latch Screw
CAUTION
Be sure to support the weight of the door
before removing the hinge screws.
5
Hold the hinge in place while removing the
four hinge screws (to prevent the door from
dropping).
Hinge Screw
6
Remove the door from the cabinet cover.
Remove
Door
