37
CONTROL PANEL
PANEL REAR [ELECTRIC]
1.
Remove 8 screws from control panel
assembly.
2.
Separate PCB from control panel.
1.
Remove 1 screw.
2.
Pull out the cover.
1.
Remove 3 screws.
2.
Disassemble terminal block and wire from
panel rear.
