Rear view
ITEM LABEL DESCRIPTION SEE PAGE:
11
1.
AC IN Connect the POWER CABLE
Rear IR receiver
(Optional)
2.
Receiver for IR signal from remote control
Connect the USB CABLE from a computer (service
only)
3.
USB (Service Only)
4.
AUDIO Connect the AUDIO CABLE from the input device
– 4 –
5.
S-VIDEO Connect the S-VIDEO CABLE from a video device
10
6.
VIDEO Connect the VIDEO CABLE from a video device
Connect the RGB CABLE from a computer and compo-
nents
7.
RGB
Secure to permanent object with a Kensington® Lock
system
35
8.
(Security Lock)
Note:
If your video equipment has both S-VIDEO and RCA jacks (composite video) connect to the
S-VIDEO connector. S-VIDEO provides a better quality signal.
