Top view—On-screen Display (OSD) buttons and LEDs
ITEM LABEL DESCRIPTION
SEE
PAGE:
1.
(POWER)
Turns the projector On or Off
2.
▲ (Up cursor) Navigates and changes settings in the OSD
18
Green Power On
Off Power Off (AC Off) 3.
POWER LED
Flashing Error code
On System over temperature
4.
TEMP LED
Off Normal State
Orange Lamp is ready to be powered-on.
5.
READY LED
Lamp not ready (Warm-up/shutting down/cooling)
(see
Flashing
LED Error Messages on page 37)
6.
MENU Open and exits the OSD buttons
◄ (Left cursor) /
SOURCE/
Detects the input device
Navigates and changes settings in the OSD
187.
▼ (Down cursor) /
VOL./KEYSTONE
Quick Menu – For Keystone, Audio Volume
Navigates and changes settings in the OSD
178.
► (Right cursor) /
AUTO/
Optimizes image size, position, and resolution
Navigates and changes settings in the OSD
7, 189.
– 3 –
To Next Page
Loading...
