LG DS40T - Appendix; Specifications

48
Appendix
Specifications
General
Power Consumption
Refer to the main label.
Networked standby: 2.0 W
AC adapter
• Model : A702-230131W-M21
• Manufacturer : Dongguan Aohai Technology Co.,Ltd.
• Input : 100 - 240 V ~ 50 / 60 Hz
• Output : 23.0 V 0 1.31 A
Dimensions (W x H x D) Approx. 720.0 mm x 63.0 mm x 87.0 mm (including the base)
Operation Temperature Range 5 °C - 40 °C
Operation Humidity Range 5 % - 80 % RH
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192
kHz
Available Digital Input Audio format Dolby Digital, DTS Digital Surround, PCM
Input/Output
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI™ d TV (ARC)
19-pin (Type A, HDMI™ connection terminal) × 1
Amplifier (RMS output)
Total 300 W RMS
Front 50WRMS×2(Impedance:4Ω,THD10%)
Subwoofer 200WRMS(Impedance:3Ω,THD10%)
