LG DS80QY User Manual

62
Appendix
Specifications
General
Power Requirement Refer to the main label.
Power Consumption
Refer to the main label.
Networked standby: 2.0 W
Dimensions (W x H x D) Approx. 1000.0 mm x 63.0 mm x 135.0 mm (including the base)
Operation Temperature Range 5 °C - 40 °C
Operation Humidity Range 5 % - 60 % RH
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio Sampling
Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format
Dolby Digital, Dobly Digital Plus, Dolby TrueHD, Dolby Atmos,
DTS Digital Surround, DTS-HD HRA, DTS-HD MA, DTS:X, IMAX DTS,
IMAX DTS:X, PCM
Input/Output
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI IN 19-pin (Type A, HDMI™ connection terminal) × 1
HDMI d TV (eARC / ARC)
19-pin (Type A, HDMI™ connection terminal) × 1
4K resolution is supported for 4K sources applied with HDCP 2.3.
Amplier (RMS output)
Total 480 W RMS
Front 45 W RMS×2 (Impedance: 4 Ω, THD 10 %)
Centre 40 W RMS (Impedance: 4 Ω, THD 10 %)
Top 45 W RMS×2 (Impedance: 4 Ω, THD 10 %)
Top centre 40 W RMS (Impedance: 4 Ω, THD 10 %)
Subwoofer 220 W RMS (Impedance: 3 Ω, THD 10 %)
Appendix

LG DS80QY Specifications

General

Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
TV Sound Share	Yes
RMS rated power	480 W
Audio output channels	3.1.3 channels
Audio sample rate (24bit)	96 kHz
Soundbar speaker RMS power	- W
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Product color	Steel
Wall mountable	-
Virtual assistant	Amazon Alexa & Google Assistant
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV
High Dynamic Range (HDR) technology	Dolby Vision
HDCP version	2.3
Bluetooth version	5.0
Number of products included	1 pc(s)

Weight and Dimensions

Depth	135 mm
Width	1000 mm
Height	63 mm
Subwoofer depth	403 mm
Subwoofer width	201.7 mm
Subwoofer height	407 mm
