LG DSL4 - Specifications

Appendix34
Appendix
5
Specifications
General
Power consumption
Refer to the main label on the unit.
Networked standby: 0.5 W
(If all network ports are activated.)
AC adapter
y
Model: DA-38A25
y
Manufacturer: Asian Power Devices Inc.
y
Input: 100 - 240 V ~ 50 - 60 Hz
y
Output: 25 V
0
1.52 A
y
Model: MS-Z1520R250-038A0-P
y
Manufacturer: MOSO POWER SUPPLY TECHNOLOGY CO., LTD.
y
Input: 100 - 240 V ~ 50/60 Hz
y
Output: 25 V
0
1.52 A
Dimensions (W x H x D) Approx. 890.0 mm X 57.0 mm X 85.0 mm With foot
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V
0
500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Audio, DTS Digital Surround, PCM
Input/Output
OPTICAL IN 3 V (p-p), Optical jack x 1
Amplier (RMS Output)
Total 300 W RMS
Front 50 W RMS x 2 (4
Ω
at 1 kHz, THD 10 %)
Subwoofer 200 W RMS (3
Ω
at 80 Hz, THD 10 %)
