LG DSN8YG User Manual

Getting Started 7
Getting Started
1
Front panel
A
1
(Standby)
- Switches the unit ON or OFF.
F (Function)
- Select the function and input source by pressing F repeatedly.
Input source / Function Display
Wi-Fi WI-FI
Bluetooth BT
Optical
ARC
e-ARC
LG Sound Sync (Wired)
OPT/HDMI ARC
HDMI IN HDMI
USB USB
,
You can use Bluetooth function after making Wi-Fi network connection by using Google Home
app.
o/p
(Volume)
- Adjusts volume level.
N
- Starts playback. / Pauses playback.
>
(Mic mute)
- Disables the detect voice recognition by pressing
>
on the unit. All the Google Assistant LED turns
amber and “The mic is muted.” is heard.
To cancel it, press
>
on the unit again. Google Assistant LED turns off and “The mic is back on.” is
heard.
- Enables Google Assistant to receive your voice commands.
To cancel it, press again. (Page 36)

LG DSN8YG Specifications

General

Audio decoders	DTS:X, Dolby Atmos
RMS rated power	440 W
Audio output channels	3.1.2 channels
Audio Return Channel (ARC)	Yes
Impedance	4 Ω
Woofer diameter	18 mm
Tweeter diameter	20 mm
Number of tweeter drivers	2
Soundbar speaker RMS power	220 W
Woofer diameter (imperial)	7 \
Subwoofer connectivity	Wireless
Display type	LCD
Product color	Black
Audio formats supported	AAC, FLAC, MP3, OGG, WAV
HDMI in	1
HDCP version	2.3
Bluetooth version	5.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Soundbar power consumption	45 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	38 W
Package depth	456 mm
Package width	1168 mm
Package height	284 mm
Package weight	14600 g

Weight and Dimensions

Depth	119 mm
Width	570 mm
Height	1060 mm
Soundbar weight	4400 g
Subwoofer depth	313 mm
Subwoofer width	221 mm
Subwoofer height	390 mm
Subwoofer weight	7800 g
