LG DSPD7Y User Manual

49
Appendix
Specifications
General
Power Consumption
Refer to the main label.
Networked standby :1.5 W
(If all network ports are activated.)
AC adapter
• Model : DA-50F25
• Manufacturer : Asian Power Devices Inc.
• Input : 100 - 240 V ~ 50 - 60 Hz
• Output : 25 V 0 2 A
• Model : MS-Z2000R250-050D0-P
• Manufacturer : MOSO POWER SUPPLY TECHNOLOGY CO., LTD.
• Input : 100 - 240 V ~ 50/60 Hz
• Output : 25 V 0 2 A
Dimensions (W x H x D) Approx. 890.0 mm x 65.0 mm x 119.0 mm (including the base)
Operation Temperature Range 5 °C - 40 °C
Operation Humidity Range 5 % - 60 %
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio Sampling
Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format Dolby Atmos®, Dolby Audio™, DTS:X®, DTS-HD, PCM
Input/Output
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI IN 19-pin (Type A, HDMI™ connection terminal) × 1
HDMI OUT (TV eARC/ARC)
19-pin (Type A, HDMI™ connection terminal) × 1
4K resolution is supported for 4K sources applied with HDCP 2.3.
Amplier (RMS output)
Total 380 W RMS
Front 30 W RMS×2 (Impedance: 4 Ω, THD 10 %)
Centre 30 W RMS (Impedance: 4 Ω, THD 10 %)
Top 35 W RMS×2 (Impedance: 4 Ω, THD 10 %)
Subwoofer 220 W RMS (Impedance: 3 Ω, THD 10 %)
Appendix

LG DSPD7Y Specifications

General

Brand	LG
Model	DSPD7Y
Category	Speaker System
Language	English
