76
■ 1140 Bottom Case
Ch5. Removing and replacing a part
1. Remove the Touchpad Connector.
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. System Door(1030), c. Retainer(1100), d. keyboard(1110), e. Button Sub
Board(1120), f. Display Module(1130)
2. Remove the 17 screws.
17
M2.5X0.45P,4.5mm,
5mm
FAB300651011
QtySpecificationFRU No.No.
