LG E500 - Page 79

79
■ 1150 Main Board
Ch5. Removing and replacing a part
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. System Door(1030), c. Retainer(1100), d. keyboard(1110), e. Button Sub
Board(1120), f. Display Module(1130), g. Bottom Case(1040)
1. Remove 1 screws.
1
M2.5X0.45,4.5mm,5
mm
FAB300651011
QtySpecificationFRU No.No.
2. Remove the Mainboard.
