LG E500 - Page 81

81
■ 1170 Speakers
Ch5. Removing and replacing a part
1. Remove 1 screws.
1
M2.5X0.45P,4.5mm,
5mm
FAB300651011
QtySpecificationFRU No.No.
2. Remove the speaker cable.
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. System Door(1030), c. Retainer(1100), d. keyboard(1110), e. Button Sub
Board(1120), f. Display Module(1130), g. Bottom Case(1040)
