LG E500 - Page 88

88
■ 1220 WLAN Antenna
Ch5. Removing and replacing a part
1. Remove 4 screws.
8
M2.5X0.45P,4.5mm,
5mm
FAB00651011
QtySpecificationFRU No.No.
2. Remove the WLAN antenna.
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. System Door(1030), c. Retainer(1100), d. Display Module(1130),
e. LCD Front Case(1200)
