22
DVD Mini Hi-Fi System ] USER GUIDE
Designs and specifications are subject to change without
pior notice.
Specifications
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 3.42 kg
External dimensions (W x H x D) 330 x 138.5x 252.4 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Tuner
FM Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
AM Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
Intermediate Frequency 450 kHz
Amplifier
OUTPUT POWER 100 W + 100 W (4Ω, THD 0.5%) : FBD203 50 W + 50 W (4Ω, THD 0.5%) : FBD103
Stereo Mode 100 W + 100 W (4Ω, THD 0.5%) : FBD203 50 W + 50 W (4Ω, THD 0.5%) : FBD103
Frequency Response 40 - 20000Hz
Signal-to-noise ratio
75dB
DVD/CD player
Frequency response (audio) 40 - 20000 Hz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz)
Signal-to-noise ratio (video) More than 75 dB (1 kHz)
Dynamic range (audio) More than 75 dB
Video output 1.0 V (p-p), 75 Ω
Component Video output (Y) 1.0 V (p-p), 75 Ω
(Pb)/(Pr) 0.7 V (p-p), 75 Ω
Speakers
FBS203V FBS103V
Type 2 Way 2 Speaker 2 Way 2 Speaker
Impedance 4 Ω 4 Ω
Rated Input Power 100W 50 W
Max. Input Power 200W 100W
Net Dimensions (W x H x D)
165 X 341 X 261 mm 165 X 341 X 261 mm
Net Weight 4.48 kg 4.03 kg
