- 2-6
-
B
NO
NO
NO
NO
NO
YES
YES
YES
YES
Laser lights
Does lens move up/down?
Check the signal of
FOCUS SEARCH
(IC801 Pin 21)
Chekc the signal of PN802
pin 13, 14
Does FE signal appear?
(IC801 pin 13)
Does DRF signal appear? (IC 801 pin67)
Defective IC801
Defective IC802
Open activator and/or connector
Defective IC801
Degraded laser diode
Defective PICK-UP
12
14
Table of Contents
Default Chapter
2
Table of Contents
2
Section 1. General
3
Servicing Precautions
3
Esd Precautions
5
Specifications
6
Section 2. Electrical
8
Adjustments
8
Tuner Adjustment
9
Troubleshooting
10
Waveforms of Major Check Point
14
Block Diagram
24
Schematic Diagrams
25
Wiring Diagram
29
Printed Circuit Diargams
30
INTERNAL BLOCK DIAGRAM of Ics
35
Repairs Regarding CD Mechanism
42
Section 3. Exploded Views
44
Cabinet and Main Frame Section
44
Tape Deck Mechanism: Auto Stop Deck(Optional)
45
Tape Deck Mechanism: Auto Reverse Deck
46
CD Mechanism
47
Section 4. Speaker
48
